Sentera 6X Thermal Pro Sensor
Synchronized multispectral, high-resolution RGB, and advanced thermal data in a single flight.
With four 3.2MP radiometric multispectral imagers, a 20MP RGB imager, and a FLIR Boson 640 radiometric thermal imager, the 6X Thermal Pro delivers four times the resolution of the 6X Thermal, ensuring unparalleled data accuracy.
Its ultra-lightweight, gimballed design, high capture rate, and 512GB internal SSD storage maximize productivity and efficiency. Ideal for advanced analytics, it seamlessly integrates data into common software platforms, empowering agronomists, researchers, and industry professionals to make informed decisions based on precise and accurate data. The Sentera 6X Thermal Pro sets a new standard in multi-sensing data capture.
Four Multispectral Bands + Radiometric Thermal
The 6X Thermal Pro captures four discrete multispectral bands plus full-color RGB across the visible and near-infrared, alongside a high-resolution radiometric long-wave thermal band (8–14 µm) — thermal and vegetation data co-registered from a single flight.
Bands shown as center wavelength × FWHM; thermal band on a broken axis. The RGB imager captures full visible color.
| Band | Center Wavelength × Width |
|---|---|
| Green | 550nm × 20nm |
| Red | 670nm × 30nm |
| Red Edge | 715nm × 10nm |
| NIR | 840nm × 20nm |
| RGB | IR cut 650nm |
| Thermal (LWIR) | 8–14 µm (radiometric) |
The Complete Dual-Sensor Intelligence Platform
Ideal for research, land management, and infrastructure inspections, the 6X Thermal Pro empowers professionals to make informed decisions with precise, detailed data.
Thermal Mapping Made Easy
6X Thermal Pro sensors are designed with thermal mapping in mind. Their synchronized and aligned imagery enables rig processing and makes orthorectifying thermal imagery more effective, producing thermal maps with ease.
Maximize Productivity
The 6X Series sensors' lightweight design, 5 FPS capture rate, synchronized image capture, and gimbal allow for faster & longer flights without sacrificing data quality — meaning you can cover more ground each flight.
Ease of Use
Plug-and-play integration on many popular UAS platforms, rig processing support, time-of-capture geo-tagging, and large internal storage reduce training requirements and streamline your workflow. 6X Series sensor data is supported in most multispectral image processing platforms.
Accuracy
Paired with an incident light sensor, calibrated reflectance panel, integrated pulse-per-second (PPS) synchronization, time-of-capture geotagging, and gimbal, 6X Series sensors are ready to produce radiometrically accurate data out of the box.
Seamless Data Layers
Vegetation Health, Thermal, Elevation, and RGB mosaics are easily overlaid with each other from their independent data layers, allowing for seamless analysis between layers and their respective features.
Advanced Visualization
Simultaneous data capture from the 6X Series sensors enables combining data types — like a hill shade derived from a DSM with a vegetation health map — to contextualize multispectral data with terrain variation.
Request a Demo
6X Thermal Pro Full Specifications
| Specification | Value |
|---|---|
| Imaging Type | 4-Band Multispectral + 20 MP RGB + Radiometric Thermal |
| Thermal Sensor | FLIR Boson+ 640 (radiometric) |
| Thermal Resolution | 640 × 512 px |
| Thermal Spectral Range | 8–14 µm LWIR (radiometric) |
| Thermal Sensitivity (NETD) | < 50 mK |
| Radiometric Output | Yes — absolute temperature per pixel |
| RGB Resolution | 20 MP (Sony CMOS) |
| Resolution | 2048 × 1536 px (Multispectral) / 5184 × 3888 px (RGB) / 640 × 512 px (Thermal) |
| Shutter Type | Global (Multispectral) / Electronic Rolling Shutter (RGB) / Shutterless (Thermal) |
| Capture Rate | 5 FPS (0.2s interval) |
| GSD @ 200ft (60m) | 1.0 in / 2.6 cm (Multispectral) / 0.4 in / 1.0 cm (RGB) / 3.4 in / 8.75 cm (Thermal) |
| Field of View | 47° HFOV (Multispectral and RGB) / 50° HFOV (Thermal) |
| Spectral Bands | Green 550nm × 20nm / Red 670nm × 30nm / Red Edge 715nm × 10nm / NIR 840nm × 20nm / RGB IR cut 650nm / Thermal (LWIR) radiometric 8–14 µm |
| Storage | 512 GB Internal SSD |
| Interfaces | USB-C 3.0, Gigabit Ethernet, PPS, Serial, Discrete I/O |
| Supported Protocols | DJI, MAVlink V1 & V2, Custom |
| Image Format | 12-bit TIFF (Multispectral) / 8-bit JPEG (RGB) / 16-bit TIFF (Thermal) |
| Vegetation Indices | NDVI, NDRE, GNDVI, OSAVI, CIre, and more |
| Radiometric Calibration | Downwelling Light Sensor (DLS) / calibrated reflectance panel |
| Synchronized Capture | Yes — thermal + multispectral in one pass |
| Weight (with gimbal) | Smart Dovetail: 515 g |
| Power Input | 10.5 – 26 V |
| Power Consumption | 15 W typical, 18 W max |
| Spec Sheet | Download 6X Thermal Pro Spec Sheet (PDF) |
Compatible with Harris Aerial Carrier Drones
The Sentera 6X Thermal Pro pairs with Harris Aerial's Carrier drone platforms. The combination of the Thermal Pro's dual-sensor capability and the Carrier's heavy-lift, extended-endurance architecture creates a deployable system for the most demanding inspection and agriculture missions.
Thermal + Spectral for Every Critical Mission
Agriculture Thermography
Detect irrigation non-uniformity, soil moisture variation, and crop temperature stress across large fields with 640×512 thermal resolution and simultaneous NDVI data.
Utility & Power Line Inspection
Identify hot spots on transmission lines, substation components, and electrical infrastructure before failures occur — with the thermal sensitivity to detect sub-degree anomalies.
Solar Array Inspection
Detect underperforming cells, string failures, and soiling patterns across photovoltaic arrays with high-resolution thermal imaging aligned to co-registered RGB documentation.
Building & Roof Inspection
Identify moisture infiltration, insulation voids, and air leakage in commercial and industrial roofing systems with absolute temperature documentation for insurance and remediation reports.
Wildfire & Fire Perimeter
Map active fire perimeters, detect hotspots obscured by smoke, and support containment operations with high-sensitivity radiometric thermal imaging from safe standoff distances.
Search & Rescue
Locate missing persons or survivors in low-visibility conditions using the Thermal Pro's LWIR thermal detection capability in conjunction with RGB imagery for ground team coordination.
How the 6X Series Compares
See how the Thermal Pro stacks up against the Multispectral and standard Thermal across specifications and recommended use cases.
| Specification | 6X Multispectral | 6X Thermal | 6X Thermal Pro |
|---|---|---|---|
| Resolution | 2048×1536 (MSP) · 5184×3888 (RGB) | + 320×256 (Thermal) | + 640×512 (Thermal) |
| Thermal Imager | N/A | FLIR Radiometric Boson 320 | FLIR Radiometric Boson 640 |
| Capture Rate | 5 FPS (0.2s) | 5 FPS (0.2s) | 5 FPS (0.2s) |
| GSD @ 200ft (60m) | 1.0in (MSP) · 0.4in (RGB) | + 6.9in (Thermal) | + 3.4in (Thermal) |
| Field of View (HFOV) | 47° (MSP & RGB) | 47° · 50° (Thermal) | 47° · 50° (Thermal) |
| Storage | 512 GB SSD | 512 GB SSD | 512 GB SSD |
| Weight (with gimbal) | 515 g | 515 g | 515 g |
| Thermal Range | N/A | 8–14 µm | 8–14 µm |
| Power Consumption | 15 W / 18 W max | 15 W / 18 W max | 15 W / 18 W max |
| Suggested Use Case | 6X Multispectral | 6X Thermal | 6X Thermal Pro |
|---|---|---|---|
| Vegetation Health Monitoring | ✓ | ✓ | ✓ |
| Water Stress Prediction | — | ✓ | ✓ |
| Thermal Mapping & Soil Moisture Analysis | — | ✓ | ✓ |
| Forest Fire & Active Flame Detection | — | ✓ | ✓ |
| Evaporation Analysis | — | — | ✓ |
| Forest Health & Vegetation Moisture | — | ✓ | ✓ |
| Crop Growth Stages & Yield Estimation | ✓ | — | — |
| Stand Count & Plant Vigor Monitoring | ✓ | ✓ | ✓ |
| Infrastructure Thermal Inspections (Solar, Roofs) | — | ✓ | ✓ |
Need help choosing? Contact the Harris Aerial team and we'll match the right sensor to your mission requirements.
Frequently Asked Questions
High-Resolution Thermal Meets Multispectral Precision
The Sentera 6X Thermal Pro is the most capable dual-sensor payload in the Carrier lineup. Let's configure your system for precision agriculture, infrastructure inspection, or utility operations.
