Carrier ATLAS

C-ATLAS is Harris Aerial’s compact and rugged NDAA compliant handheld Ground Control Station.  C-ATLAS combines rugged design, powerful computing, and a strong broadband datalink to make the ultimate GCS.  Harris Aerial’s HA Ground Control software enables real-time telemetry information, video streaming, and mission planning all from a single controller.


Elevating Ground Control Capabilities

8 inch HD Display

Large HD sunlight-viewable screen with 1920 x 1200 resolution.

NDAA Compliant

C-ATLAS is fully compliant with the 2020 National Defense Authorization Act, Sec 848

Easy Integration

Fly any of our UAVs or others using our revolutionary HA QGC mission planning software.


Based on open source MAVLink communication protocol enabling support with HA QGC and various other GCS softwares.


C-ATLAS offers various connectivity options including high-bandwidth long-rang AES-256 encrypted data channel, LTE and WIFI.

Rugged & Tactical Design

IP-68 rated design allows to operate in the most harsh environments

Complete Control

Powerful Control

C-ATLAS’ high bandwidth 2.4GHz modem allows for long range transmission of drone telemetry data, high resolution video, manual control and payload data.

Ergonomic design

C-ATLAS perfectly fits in operator hands and allows continuous work.  Its IP68 rating allows for dust protection and water resistance.


Masterful Design: Explore the Precision

  • Processing and Memory:
  • CPU Octa Core, 2.7GHz
  • RAM 4GB
  • ROM 64GB
  • External MicroSD (Up to 1TB)
  • Radio
  • Technology 2x2 MIMO
  • Frequency 2402 - 2482 MHz
  • Power up to 30 dBm / 1W
  • Bandwidth 4 / 8 MHz
  • Encryption AES
  • Data Rate 25 Mbps
  • Latency < 100 ms
  • Software
  • Operating System Android
  • Environment
  • Durability IP-68
  • Ambient Temperature -40...+50°C
  • Screen
  • Size 8"
  • Touch Capacitive, high-sensitive
  • Resolution 1920 x 1200 (WUXGA)
  • Size and Weight
  • Size 286x165x55 mm
  • Weight 1140 g
